0.8T Capacity Tirfor Manual Wire Rope Hoist with 20m Wire Rope and 1 Year Warranty
Premium Products
0.8T Capacity Tirfor Manual Wire Rope Hoist with 20m Wire Rope and 1 Year Warranty
1
2
3
Brand Name :Xinya
Place of Origin :Jiangsu, China
Certification :ISO
MOQ :2
Price :$30-200
Lifting Speed :Manual
Sling Type :Wire Rope
Power Source :Hand Chain
Weight :3200 kg
Net Weight :6.4 kg
Rated Capacity :800 kg
Rope Diameter :8.3 mm
Max Traveling Load :1200 kg
Material :Steel
Max Outer Size :426 mm
Length L2 :238 cm
Wire Rope Length :20 m
Rope Safety Factor :5
Rated Forward Hand Power :341 N
Rated Forward Travel :≥52 mm
Contact Now
Product Description
0.8T Tirfor Manual Wire Rope Hoist With 20m Wire Rope for Lifting and Pulling
Detail Introduction
Hand winch is a kind of small-sized, compact, hand-operated lifting tool. It' s features is light weight, compact structrue, wide range of applications and easy maintenance. This type of hoist is suitable to use outdoor sites under advise circumstances.
The housing of the hoist is made of aluminum alloy, thus producing adequate strength, light in weight and making it quite portable, while the component parts inside are made of high quality alloyed steel with advanced technology. Strict quality control test have been carried out on all the component parts. As for the major parts subject to high tension are tested according to ISO standards even with overloading to ensure top quality.
It is a kind of newly designed, uncomplicated structured, convenient-to-use lever hoist with the function of adjusting the beneath-hook quickly, safe and reliable. its new style, beautiful body, good braking performance and high working efficiency enable it to be able to be widely used in factory, mineral, building site, Harbor and transportation areas and so on. It is the ideal equipment for Equipment installation, object fixing, tying and towing, world famous qualified product both home and aboard.
Use and Characteristic
1) Capacity: 0.8T x 20M, 1.6T x 20M, 3.2T x 20M, 5.4T x 20M.
2) All hoists are supplied complete with 20 meter wire rope and an extendable operating lever.
3) Wire rope is tapered one end and fitted with a hook and safety catch at the other end.
3) The hoist has low maintenance requirements and is easy service.
4) Overload protection ensures high personal safety when in operation.
5) Specially built-in shear pins can be replaced without removing the load.
